480V 125kVAr Static Var Generator module

YT ELECTRIC has been offering a comprehensive range of key components for Automatic Power factor correction (APFC) and power quality solutions for many years. The rapid development of industry and infrastructure resulted in the increased usage of power electronic loads which demands a highly dynamic response time for reactive power compensation. Conventional reactive power compensation only with passive components cannot fully meet these conditions, especially when the reactive power requirement is rapidly changing.

YTPQC-SVG Static Var Generator is a revolutionary new standard with three level inverter topology in the field of reactive power compensation. When the load generates inductive or capacitive reactive current, it will make the load current to lag or lead the voltage in real time. YT ELECTRIC is pleased to offer our range of SVGs for high effective response to power quality issues in low and high voltage power systems.

YTPQC-SVG is a new approach to power factor correction, load balancing and harmonics mitigation. The modular design and compact structure make it the ideal solution for active stepless reactive power compensation, load balancing and harmonics mitigation in industrial applications and commercial buildings. Compared to conventional power factor correction systems, YTPQC-SVG offers a response time of less than 5 ms and a dynamic reaction time of less than 50 µs. It can compensate both inductive and capacitive loads and achieve a power factor of 0.99 (1).

Our 480V Static var Generator modules include 40kVAr,60kVAr,80kVAr,125kVAr Module, support 50Hz and 60Hz in three phase four wire networks.  The 125kVAr SVG modules are widely used in Mexico,Colombia,India,etc.

YT ELECTRIC is the biggest OEM manufacture of low voltage Static Var Generator and Active Harmonic Filter. Welcome to contact us for further information.
