YT Patent introduction: An outdoor reactive power compensation device

With the development of society and the increase of demand for electricity, Reactive power compensation technology has developed rapidly, including Static VAR Compensation and Dynamic Reactive Power compensation, and has gained rich operating experience. However, some problems have also been exposed in practice. Some reactive power compensation devices are inconvenient to move, and the equipment maintenance is cumbersome, which greatly affects the efficiency and reliability of reactive power compensation. At the same time, since there are many electrical components in the shell of reactive power compensation equipment, especially capacitors and reactors, the heat dissipation is large during operation, which increases the temperature inside the shell of the device. If the heat dissipation is not timely, it is easy to cause local overheating, thereby affecting reactive power. The normal operation of the compensating device can even cause large losses.

The utility model patent provides an Static var generator power factor control system, including: a transformer, a charging cabinet, a power cabinet, and a control cabinet. The transformer is connected to the grid, and is used to convert the grid voltage into a preset voltage to supply power to the SVG control system; The input end of the charging cabinet is connected to the transformer, the output end of the charging cabinet is respectively connected to the power cabinet and the control cabinet, and the charging cabinet is used to supply power to the power cabinet and the control cabinet.
