What are Reactive Power and Reactive Power compensation？

Reactive power is a key part of AC electrical systems—it’s the energy that flows back and forth between the power source and the load.

Unlike active power, which does the actual work like powering lights or running machines, reactive power doesn’t directly get used up. But it plays a crucial role in keeping voltage levels steady, making sure electrical equipment works properly, and keeping the power grid stable.

Understanding Reactive Power

In AC circuits, reactive power arises due to the presence of inductive and capacitive elements, such as motors, transformers, and capacitors. These components cause the current to either lag or lead the voltage, creating a phase difference. This phase difference results in the circulation of reactive power, measured in volt-amperes reactive (VAR). While it doesn't perform useful work, reactive power is crucial for:

• Voltage Regulation: Maintaining appropriate voltage levels across the network to ensure the proper functioning of electrical devices.
• Efficient Power Transmission: Supporting the transfer of active power through the grid by sustaining the necessary electromagnetic fields.

Reactive Power Compensation

Reactive power compensation involves the management and optimization of reactive power to enhance the performance and efficiency of electrical power systems. The primary objectives of reactive power compensation include:

• Improving Power Factor: The power factor is the ratio of active power to apparent power in a circuit. A low power factor indicates a high presence of reactive power, leading to inefficiencies. Compensation techniques aim to bring the power factor closer to unity, reducing losses and improving system efficiency.
• Voltage Stability: By compensating for reactive power, voltage levels can be stabilized, preventing issues such as voltage sags or swells that can damage equipment or disrupt operations.
• Enhanced Transmission Capacity: Effective reactive power management allows for the optimal utilization of existing transmission infrastructure, potentially deferring the need for costly upgrades.

Methods of Reactive Power Compensation

Several methods are employed to achieve reactive power compensation, each suited to specific applications and system requirements:

1. Shunt Capacitors: Connected in parallel with the load, shunt capacitors provide leading reactive power, counteracting the lagging reactive power of inductive loads. This method is commonly used for power factor correction in industrial settings.
2. Series Capacitors: Installed in series with transmission lines, these capacitors reduce the line's inductive reactance, improving voltage stability and increasing power transfer capability.
3. Synchronous Condensers: These are synchronous machines operated without a mechanical load, capable of generating or absorbing reactive power as needed. They offer smooth and continuous control but come with higher installation and maintenance costs.
4. Static VAR Compensators (SVCs): SVCs are power electronic devices that provide fast-acting reactive power compensation. They adjust the reactive power output by switching capacitors and reactors, effectively stabilizing voltage levels in real-time.
5. Static Synchronous Compensators (STATCOMs): An advanced form of reactive power compensation, STATCOMs use voltage source converters to provide dynamic reactive power support, offering superior performance in voltage regulation compared to traditional methods.
6. Static Var Generators (SVGs)

SVGs are a modern and highly efficient solution for reactive power compensation. Using advanced inverter technology, SVGs can deliver real-time inductive or capacitive reactive power with precision, enhancing power factor correction, voltage stability, and harmonic filtering.

For example, YT Electric offers a wide range of SVG solutions, from rack-mounted units to cabinet systems, capable of correcting power factors, eliminating harmonics up to the 25th order, and managing three-phase imbalances. SVGs are especially suitable for environments requiring high efficiency, reliability, and adaptability, such as industrial facilities or renewable energy installations.

YT Electric's Solutions for Reactive Power Compensation

Shanghai Yingtong Electric Co., Ltd (YT Electric) is a pioneer in power quality solutions, specializing in the research, development, production, and sale of advanced reactive power compensation equipment. Their product lineup includes:

• Active Power Filters (APF): Designed to mitigate harmonics and provide dynamic reactive power compensation, improving power quality and system reliability.
• Static Var Generators (SVG): Also known as Static Synchronous Compensators (STATCOMs), YT Electric's SVGs offer fast response times and precise reactive power control, enhancing voltage stability and power factor correction.

Benefits of Implementing YT Electric's Solutions

By incorporating YT Electric's reactive power compensation products, utilities and industrial facilities can achieve:

• Enhanced Power Quality: Reduction in harmonics and improved voltage profiles lead to more reliable and efficient operations.
• Operational Efficiency: Optimized power factor and reduced losses result in lower energy costs and improved utilization of electrical infrastructure.
• Scalability and Flexibility: YT Electric's solutions are designed to adapt to varying load conditions and can be scaled to meet future expansion needs.
• Compliance with Standards: Ensuring adherence to international power quality standards, thereby avoiding potential penalties and enhancing system compatibility.

Conclusion

Reactive power and its effective compensation are critical components of modern electrical power systems. Proper reactive power management improves system efficiency, voltage stability, and overall power quality.

YT Electric is the biggest OEM manufacturer of low-voltage AHF and SVG with more than 15 years' experience. All products hold certifications for ISO9001, CE, and CQC standards, and type test reports support them. YT Electric's comprehensive range of products offers tailored solutions to meet the diverse needs of today's power networks, ensuring reliable and efficient operation in an increasingly complex electrical landscape.
