Enhancing Power Quality in UPS Systems
Uninterruptible Power Supply (UPS) systems are essential for maintaining continuous operations in environments such as data centers, hospitals, and industrial facilities. However, the non-linear loads common to UPS systems can introduce harmonic distortions. These distortions not only degrade power quality but may also lead to equipment malfunctions.
YT Electric’s Active Harmonic Filters (AHFs) offer a modern solution to these problems. They help UPS installations work reliably and efficiently.
Understanding Harmonic Distortions in UPS Systems
Harmonics are additional voltage or current waveforms that occur at multiples of the fundamental frequency. They typically emerge from non-linear electrical loads, such as those found in UPS systems.
When these unwanted waveforms are present, they can cause many problems. These include overheating, higher energy losses, and interference with sensitive electronic devices. Recognizing and mitigating harmonic distortions is, therefore, a key step in safeguarding the integrity and safety of electrical systems.
Below are some of the most common power quality issues encountered by UPS systems:
Voltage can change suddenly. We call these changes voltage dips. They can occur due to an unstable power supply, changes in load, or line losses. These fluctuations can prevent the UPS from providing a stable output voltage, potentially disrupting the operation of connected equipment.
Voltage spikes, surges, or transients are brief electrical disturbances. They often happen due to events like lightning strikes, switching operations, or recovering from power supply faults. These issues can damage internal components of the UPS and the connected devices, compromising the overall system’s reliability.
Non-linear loads in UPS systems can create harmonic distortions. These distortions show up as changes in the ideal sinusoidal waveform of voltage or current. Harmonic distortion reduces power quality, increases equipment heat generation, shortens device lifespans, and can interfere with the performance of sensitive electronics.
High-frequency noise and transient interference can be generated by external devices or internal power conversion processes.
These disturbances can harm the monitoring and regulation functions of the UPS. This can lead to poor power quality and may affect the performance of connected equipment.
Instability in the grid frequency can also affect UPS systems, leading to deviations from the desired output frequency. This can have adverse effects on sensitive equipment that relies on precise frequency control.
UPS systems can have issues like amplitude damping oscillations or power line interference. These problems may cause slower responses or incorrect actions. This compromises the continuous and stable supply of power.
How Active Harmonic Filters Work
Active Harmonic Filters are designed to dynamically neutralize the adverse effects of harmonic distortions. They work by injecting compensating currents into the system, effectively cancelling out the undesirable harmonics. This process improves power quality and reduces stress on important equipment. This helps make your electrical systems more efficient and last longer.
Key Features of YT Electric’s Active Harmonic Filters
Real-World Impact and Compliance
YT Electric’s AHFs have been successfully implemented across a wide range of applications worldwide. Facilities with extensive UPS systems have experienced significant improvements in power quality and operational efficiency. These filters meet international power quality standards. This means your system works better and follows the rules.
Contact Us
Integrating YT Electric’s Active Harmonic Filters into UPS systems is a smart choice. It helps remove harmonic distortions, improve power quality, and protect important operations for a longer time.
As we depend more on constant power, advanced harmonic mitigation technologies are crucial. They help keep our electrical systems safe and efficient.
YT Electric is the biggest OEM manufacturer of low-voltage AHF and SVG with more than 15 years' experience. All products hold certifications for ISO 9001, CE, and CQC standards, and type test reports support them.
For more information on how our AHFs can help improve power quality: contact us at sales@ytelect.com.
