The inductor is a component that can convert electrical energy into magnetic energy and store it. The structure of the inductor is similar to that of a transformer, but there is only one winding, which only hinders the change of current. If the inductor is in the state of no current passing through, when the circuit is connected It will try to hinder the flow of current through it. If the inductor is in the state of current passing, it will try to maintain the current when the circuit is disconnected. Inductance is widely used in telegraphs, telephones, etc. When using the wall-mounted type for installation, due to the heavy weight of the inductor itself, it will cause great difficulty for the installer during the long-term lifting process.
The utility model patent relates to the technical field of inductors, and specifically discloses an inductor installation structure of a wall-mounted power module, which includes a mounting plate and an inductor main body. The top and bottom of the right side of the mounting plate are provided with threaded grooves. A hole is opened in the middle of the right side, a base is fixedly connected to the left side of the inductor main body, a threaded rod is threadedly connected to the left side of the base, and one end of the threaded rod enters the inner wall of the threaded groove after passing through the base; By arranging a round rod on the base of the main body of the inductor, the utility model can use the baffle plate on the round rod to fit the installation board, and then cooperate with the movable components and the fixed components at the bottom of the receiving board to resist the installation board, and then can It plays the role of supporting the main body of the inductance, and the use of the threaded groove and the threaded rod can finally complete the installation of the main body of the inductance, which solves the difficult problem of lifting the main body of the inductance during the installation process.
