An Analysis of Power Quality Problems and its Mitigation

Introduction

Power quality refers to the characteristics of electric power supplied to end users, particularly its ability to ensure the proper functioning of electrical devices. With the increasing use of sensitive equipment such as programmable logic controllers, variable frequency drives (VFDs), and computers in modern industries, the tolerance for power disturbances such as voltage dips, swells, and harmonic distortion has decreased. These disturbances can cause severe equipment malfunction, system failure, and operational downtime. Consequently, power quality management has become paramount for industrial facilities and critical infrastructure like hospitals.

One of the most effective solutions for mitigating these issues is the deployment of power quality correction devices like the Active Harmonic Filter (AHF) and Static Var Generator (SVG). These devices help eliminate harmful distortions, improve the overall power quality, and reduce the risk of equipment failure.

How Power Quality Problems Develop

Power quality disturbances originate from various sources and can affect industrial equipment in numerous ways. The development of power quality problems requires three key elements:

1. A Source: A disturbance originating from either the utility grid or internal equipment.
2. A Coupling Channel: How the disturbance enters the power system.
3. A Receptor: The equipment that is adversely affected by the disturbance.

Once a disturbance enters the system, it can spread through the network and disrupt equipment operations. For example, the coupling of harmonics from electronic loads (e.g., VFDs or fluorescent lighting) can lead to overheating of transformers and circuit breakers.

Power Quality Problems and Their Impact

Power quality issues manifest in several forms, each having distinct causes and effects:

• Voltage Dips: A decrease in voltage below nominal levels can disrupt sensitive equipment, such as industrial machines and electronic systems.
• Voltage Swells: These brief increases in voltage can damage equipment, including motor drives and power electronics.
• Harmonics: Non-linear loads like VFDs and electronic devices generate harmonic currents that distort the sine wave of the voltage, causing equipment to overheat and resulting in inefficiencies.
• Power Outages: Total loss of power can cause operational shutdowns, leading to significant financial losses.

In addition to these common problems, voltage transients (spikes) and electrical noise can also degrade equipment performance. Effective mitigation is essential to prevent these issues from escalating.

Causes of Power Quality Issues

Power quality disturbances can be traced back to several causes:

• Voltage Fluctuations: Caused by large equipment start-up/shutdown or sudden changes in load, affecting motors, drives, and other sensitive equipment.
• Harmonics: Generated by electronic ballasts, VFDs, and other non-linear loads, leading to overheating and potential equipment failure.
• Power Outages: Occur due to external factors like weather or system faults, resulting in total disruption of operations.

To mitigate these effects, technologies like Active Harmonic Filters (AHF) are employed to reduce harmonic distortion, while Static Var Generators (SVG) provide real-time compensation for reactive power imbalances, helping stabilize the system.

Solutions to Power Quality Problems

Addressing power quality issues requires a multifaceted approach. Several mitigation strategies can be implemented:

1. Harmonic Filters

Harmonic filters are crucial for reducing the distortion caused by non-linear loads. YTPQC's Active Harmonic Filter (AHF) is a state-of-the-art solution for eliminating harmonics in industrial and commercial systems. The AHF dynamically detects and filters out unwanted harmonics, ensuring smooth and stable voltage profiles that enhance equipment lifespan and reduce operational disruptions.

2. Static Var Generators (SVG)

YTPQC's Static Var Generator (SVG) provides real-time reactive power compensation, particularly useful in correcting power factor issues and stabilizing voltage in systems with significant imbalances. By addressing these imbalances, the SVG improves overall system efficiency and prevents damage to electrical equipment.

3. Energy Storage Systems

Energy storage solutions, such as uninterruptible power supplies (UPS) and batteries, provide critical backup during voltage sags or outages, ensuring the continuity of operations.

4. Surge Arresters and Thyristor-Based Switches

These devices protect sensitive equipment from voltage spikes and surges caused by external factors like lightning or power line switching. Thyristor-based static switches are particularly effective at addressing voltage fluctuations in real-time.

5. Isolation Transformers

Isolation transformers are used to decouple sensitive equipment from electrical disturbances and to provide a stable voltage supply, ensuring that the load remains protected from common-mode noise and voltage fluctuations.

Power quality remains a significant concern for modern industries, as even slight deviations in voltage or current can lead to substantial equipment damage and financial losses. Solutions such as YTPQC’s Active Harmonic Filter (AHF) and Static Var Generator (SVG) are essential tools for mitigating power quality issues. By integrating these technologies, industries can significantly improve their operational efficiency, reduce downtime, and enhance the lifespan of their equipment.

As industries continue to rely on increasingly sensitive electronic devices, ensuring stable and clean power delivery will be key to maintaining productivity and preventing costly failures. Power quality solutions like the AHF and SVG are no longer just a luxury but a necessity for safeguarding modern industrial operations.

Any interest or questions, welcome to contact us: sales@yt-electric.com
